| EA Steel-making Electric Arc Furmace Parameter |
| View：1058 Datetime：2011-04-26 10:20:43 |
| Type |
Nominal Capacity (t) |
Size of Furnace Body And Transformer Room (mm) |
|
|
|
|
|
|
|
|
|
Hopper |
|
|
|
Crown Block |
|
|
|
| |
|
A |
B |
C |
D |
E |
F |
G |
H |
J |
I |
Inside Capacity (m3) |
K |
L |
M |
Crane Ladle |
|
Charge Crown Block |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Major |
Assistant |
Major |
Assistant |
| EA-215 |
2 |
1500 |
3000 |
1500 |
1000 |
4500-5000 |
6000 |
7000 |
8200 |
9300 |
5400 |
2 |
1250 |
2350 |
3050 |
5 |
2 |
5 |
3 |
| EA-245 |
3 |
1700 |
3200 |
1600 |
1400 |
5000-5500 |
6500 |
7500 |
8280 |
9370 |
5910 |
4 |
1500 |
2550 |
3450 |
7.5 |
2.5 |
8 |
3 |
| EA-275 |
5 |
1700 |
3200 |
1600 |
1400 |
5000-5500 |
6500 |
7500 |
8320 |
9400 |
6270 |
5 |
1700 |
2750 |
3700 |
10 |
3 |
10 |
4 |
| EA-305 |
8 |
1700 |
3900 |
1700 |
1900 |
5500-6000 |
7000 |
8000 |
8370 |
9540 |
6430 |
7 |
2000 |
2750 |
3850 |
20 |
7.5 |
12.5 |
5 |
| EA-335 |
10 |
1700 |
3900 |
1700 |
1900 |
5500-6000 |
7500 |
8500 |
8390 |
9700 |
6940 |
10 |
2250 |
2900 |
4300 |
20 |
7.5 |
16 |
7.5 |
| EA-365 |
15 |
2600 |
5100 |
2700 |
3000 |
6000-6500 |
8000 |
9000 |
8400 |
9980 |
7350 |
14 |
2500 |
3200 |
4600 |
30 |
10 |
25 |
7.5 |
| EA-395 |
20 |
2800 |
5300 |
2800 |
3200 |
6500-7000 |
10000 |
12000 |
8510 |
10100 |
7600 |
16 |
2650 |
3250 |
4750 |
40 |
15 |
31.5 |
10 |
| EA-410 |
25 |
2800 |
5500 |
2800 |
3200 |
7000-8000 |
10000 |
12000 |
8500 |
10100 |
7910 |
19 |
2850 |
3400 |
5000 |
50 |
15 |
31.5 |
10 |
| EA-460 |
30 |
3200 |
5900 |
2900 |
3400 |
7500-8500 |
10000 |
12000 |
9940 |
11800 |
8480 |
23 |
3000 |
3550 |
5400 |
60 |
20 |
40 |
15 |
| EA-500 |
40 |
3250 |
6400 |
3200 |
3600 |
8000-9000 |
10000 |
12000 |
9990 |
11900 |
8810 |
29 |
3400 |
3700 |
5650 |
80 |
20 |
50 |
20 |
| EA-520 |
50 |
3500 |
6500 |
3300 |
3950 |
8000-9000 |
10000 |
12000 |
9940 |
11900 |
9100 |
35 |
3700 |
3800 |
5900 |
100 |
30 |
63 |
25 |
| EA-550 |
60 |
3550 |
7200 |
3600 |
4250 |
8500-9500 |
10000 |
12000 |
10000 |
12000 |
9510 |
41 |
3950 |
3950 |
6200 |
120 |
30 |
80 |
25 |
| EA-580 |
70 |
3700 |
7200 |
3800 |
4450 |
9000-10000 |
10000 |
12000 |
10100 |
12100 |
9870 |
47 |
4200 |
4050 |
6450 |
150 |
40 |
80 |
30 |
| EA-610 |
80 |
3900 |
7400 |
4000 |
4650 |
9500-10000 |
11000 |
12000 |
10100 |
12200 |
10180 |
55 |
4500 |
4200 |
6650 |
150 |
40 |
100 |
40 |
| EA-630 |
100 |
4100 |
7500 |
4100 |
4750 |
10000-10500 |
11000 |
12000 |
11000 |
13200 |
10700 |
63 |
4600 |
4350 |
7000 |
200 |
50 |
125 |
50 |
| EA-680 |
125 |
4300 |
7600 |
4200 |
4850 |
10000-11000 |
11000 |
12000 |
11400 |
13500 |
10900 |
72 |
5000 |
4400 |
7300 |
200 |
50 |
125 |
50 |
| EA-760 |
200 |
4500 |
8500 |
4500 |
5450 |
10500-12000 |
12000 |
13000 |
12100 |
14400 |
11790 |
100 |
5600 |
4700 |
8150 |
300 |
60 |
160 |
60 | |
|
|
|
|
